Tsugami Mfg., Co., Ltd was established in Nagaoka-shi, Niigata pref. Production of block gauge was started in 1937. Precision Tsugami, headquartered in Tokyo, Japan, specializes in manufacturing high-precision CNC Lathes, Turning Centers, Machining Centers and Multi-Tasking Machines, for the machining of small-parts around the world.
Founded in 1923, the company is now the largest machine tool builder in the world specializing in technology for machining small parts (.5 to 38mm). Small parts require sophisticated CNC machine tools that deliver high speed, superb accuracy, and unparalleled precision.
Since its inception, Precision Tsugami has pioneered many innovations in the development of CNC Lathes featuring a sliding headstock, known as Swiss type lathes or Swiss Turns, a tradition that continues today. For many years, Precision Tsugami machine tools were referred to as “Swiss style” lathes, or simply Swiss machines, for their sliding headstock features. While Precision Tsugami still sets the standard for Swiss Turning of small diameter parts, recent technology advances now make many of our models uniquely suited to manufacture all types of small parts.
Swiss type lathes are usually reserved for long runs of high precision small parts. Today’s extended range of Tsugami CNC machine tools also contain features that enable a manufacturer to produce small parts in short runs, with easy set-up and fast changeover times. Optional “chucker”kits also transform the sliding headstock Swiss Type Lathes into a traditional CNC Lathes, or Turning Centers providing extra flexibility for a machine shop. Current industries served: aerospace, automotive, optical, medical, surgical implant, optics, camera, and office automation.
Precision Tsugami was founded in Japan in 1923 as a manufacturer of gauge blocks. In the machine tool industry, gauge blocks are used to measure and benchmark the overall accuracy of parts machined on various machine tools. Incredible accuracy is required to manufacture them, and the fledgling company delivered it with their first product!
This unbending dedication to accuracy soon became the hallmark of Precision Tsugami, and established a tradition of excellence which is honed and refined in every product manufactured today.
Today, Tsugami Precision is the global leader specializing in CNC machine tools which make high-precision small parts (.5 to 38mm). In addition to its headquarters in Tokyo, Japan, Precision Tsugami operates modern manufacturing plants in Japan (3) and China (1).
Precision Tsugami’s newest manufacturing plant is located in the Pinghu Economic Development Zone of Zhejiang, China. The complex of 9 modern buildings comprises 420,000 sq. ft. and is a masterpiece of modern manufacturing technology. Production processes and innovations in the new facility mirror those of our Nagaoka, Japan flagship facility. The plant is ISO 9001 certified, and capable of producing more than 1,000 units per month to exacting Tsugami standards. It is vertically integrated to ensure the highest quality.
“Everything we do is underpinned by our management policy of “Integrated Quality”. We focus particularly on “speeding up customer service”, that we can respond quickly to our customers’ needs, and on “constantly striving to make provements”, based on our determination to resolve problems. On behalf of the Nagaoka Factory, we have set out the following Quality Policy in line with that underlying management policy.
- 1. We will always put quality first, in order to earn customers’ trust and ensure satisfaction.
- 2. We will take responsibility for the quality of each process, to prevent issues affecting subsequent processes.
- 3. We will focus on education, training and improvement activities, in order to continually improve quality.”
From Manager, Nagaoka Factory, 2013
Product range:
CNC Precision Automatic Lathe
Best for mass production of high-precision small components such as parts for office automation (OA) equipment, medical equipment, digital camera, cellular phone, optical communications and automobile.
- Independent Opposed Gang tool type
- Opposed Gang tool type
- Gang-tool slede & turret
- Chuck work
Independent Opposed Gang tool type
| Model | Max. machinable dia. | Max. number of tools |
Back spindle | Cross-rotary tools | |
|---|---|---|---|---|---|
 |
CNC PRECISION AUTOMATIC LATHEB0128W/B0208W | φ12・φ20 | 25 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEBW269Z/BW329Z | φ26・φ32 | 29 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEBW127/BW128/BW128Z/BW129Z BW207/BW208/BW208Z/BW209Z |
φ24・φ28 | 25 | ○ | ○ |
Opposed Gang tool type
| Model | Max. machinable dia. | Max. number of tools |
Back spindle | Cross-rotary tools | |
|---|---|---|---|---|---|
 |
CNC PRECISION AUTOMATIC LATHEP013/P033/P014/ P034 |
φ1・φ3 | 11/14 | ○(except 3-axis) | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB073-Ⅲ/B074-Ⅲ/ B075-Ⅲ |
φ7 | 13/17/21 | ○(except 3-axis) | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB0123-Ⅲ/B0124-Ⅲ/ B0203-Ⅲ/B0204-Ⅲ |
φ12・φ20 | 13/17 | ○(except 3-axis) | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB0125-Ⅲ/B0205-Ⅲ | φ12・φ20 | 21 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB0126-Ⅲ/B0206-Ⅲ | φ12・φ20 | 25 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB026/32-Ⅲseries B026V/32V-Ⅲseries |
φ26・φ32 | 27/31/39/43 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB038-Ⅲseries/B038V-Ⅲseries | φ38 | 29 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEBM163-Ⅲ/BM164-Ⅲ/ BM165-Ⅲ |
φ16 | 13/17/21 | ○(except 3-axis) | ○ |
 |
CNC PRECISION AUTOMATIC LATHES205A/206A-Ⅱ | φ20 | 22/26 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHES205/206 | φ20 | 24/28 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHE SUPER SWISSTURNSS26/32 SS32L | φ26・φ32 | 24 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHESS207/SS207-5AX | φ20 | 35 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHESS267-Ⅲ/SS327-Ⅲ/ SS267-Ⅲ-5AX/ SS327-Ⅲ-5AX |
φ26・φ32 | 38 | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB038M/SS38MH/SS38MH－5AX | φ38 | ○ | ||
Gang-tool slede & turret
| Model | Max. machinable dia. | Tool post style | Back spindle | Cross-rotary tools | |
|---|---|---|---|---|---|
 |
CNC PRECISION AUTOMATIC LATHEBH20Z | φ20 | Gang tool+12pos.turret | ○ | ○ |
 |
CNC PRECISION AUTOMATIC LATHEB038T | φ38 | Gang tool+8pos.turret | ○ |
○ |
Chuck work
| Model | Chucking capacity | X・Z axis stroke | Least input increment | |
|---|---|---|---|---|
 |
CNC HIGH PRECISION AUTOMATIC LATHEC180 | 3,4 inch | 300×150 | 0.01μm |
 |
CNC HIGH PRECISION AUTOMATIC LATHEC150 | 3 inch | 150×150 | 0.01μm |
 |
CNC HIGH PRECISION AUTOMATIC LATHEC220 | 4 inch | 220×220 | 0.01μm |
 |
CNC HIGH PRECISION AUTOMATIC LATHEC300-Ⅳ | 6 inch | 300×300 | 0.1μm |
 |
CNC HIGH PRECISION AUTOMATIC LATHEC300H | 6 inch | 300×300 | 0.1μm |
 |
CNC HIGH PRECISION AUTOMATIC LATHECH154 | φ15 | 300/300×150/120 | 0.01μm |
CNC Lathe
CNC lathe M series correspond to bar machining and chucker.
From simple turning machine to highly complex machine are well suited for components of automobile and constraction machines.
- Turret
Turret
| Model | Max. machinable dia. | Tool post style | Back spindle | Rotary tools | |
|---|---|---|---|---|---|
 |
CNC LATHEM06JC-Ⅱ | 6 inch | 8pos.turret | × | × |
 |
CNC LATHEM06J-Ⅱ/M08J-Ⅱ | 6 inch・8 inch | 8pos.turret | × | × |
 |
CNC LATHEM08JL5-Ⅱ | 8 inch | 8pos.turret | × | × |
 |
CNC LATHEM08JL8-Ⅱ | 8 inch | 8pos.turret | × | × |
 |
CNC LATHEM06D-Ⅱ/M08D-Ⅱ | 6 inch・8 inch | 12pos.turret | × | ○ |
 |
CNC LATHEM06DY-Ⅱ/M08DY-Ⅱ | 6 inch・8 inch | 12pos.turret | × | ○ |
 |
CNC LATHEM06SJ-Ⅱ/M08SJ-Ⅱ | 6 inch・8 inch | 12pos.turret | ○ | × |
 |
CNC LATHEM06SD-Ⅱ/M08SD-Ⅱ | 6 inch・8 inch | 12pos.turret | ○ | ○ |
 |
CNC LATHEM06SY-Ⅱ/M08SY-Ⅱ | 6 inch・8 inch | 12pos.turret | ○ | ○ |
Precision Turning Center
Precision Turning Center
The multiplex machine which performs turning and machining
Best for processing complicated workpieces
- Chuck work
Chuck work
| Model | Chucking capacity | Tool storage capacity | Back spindle | Tool post style | |
|---|---|---|---|---|---|
 |
TURNING CENTERTMA8J | 8 inch | 60ATC | ○ | Tool spindle with standard Y-axis control and B-axis indexing |
 |
TURNING CENTERTMA8H | 8 inch | 60ATC | ○ | Tool spindle with standard Y-axis control and B-axis indexing |
 |
TURNING CENTERTMA8F | 8 inch | 60ATC | ○ | Tool spindle equipped with Y axis control and continuous controlled B-axis |
Precision Machining Center
Versatile machine to cover various components processing at customer's request;
from steel parts of automobile and industrial equipment, to aluminum parts of home electric appliance, office automation (OA) equipment and IT-related equipment.
Realized space saving, high-speed and high-precison processing.
- Vertical Machining Center
- Horizonal Machining Center
Vertical Machining Center
| Model | Spindle I.D. taper | X・Y・Z axis stroke |
Table size |
Spindle speed (min-1) |
|
|---|---|---|---|---|---|
 |
HIGH SPEED VERTICAL MACHINING CENTERVA2 | 7/24 taper S20T | 360×260×250 | 500×330 | 30,000 |
 |
HIGH SPEED VERTICAL MACHINING CENTERVA3/VL3 | 7/24 taper No.30 | 500×400×350 700×450×350(VL3) | 650×400 850×450(VL3) | 20,000 10,000(VL3) |
 |
VERTICAL MACHINING CENTERVA4 | 7/24 taper No.40 | 720×510×460 | 850×510 | 10,000 |
Horizonal Machining Center
| Model | Spindle I.D. taper | X・Y・Z axis stroke |
Table size | Spindle speed (min-1) |
|
|---|---|---|---|---|---|
 |
HIGH SPEED PRECISION HORIZONTAL MACHINING CENTERFMA3-Ⅲ | 7/24 taper No.40 | 360×330×400 | 300 | 10,000 |
 |
HIGH SPEED PRECISION HORIZONTAL MACHINING CENTERFMA5-Ⅲ | 7/24 taper No.40 | 560×350×500 | 8P:450 10P:300 | 10,000 |
Precision Grinding Machine
Corresponds to wide grinding processing from stand-alone machine to full automatic grinding system
- Cnc Cylindical Grinding Machine
Cnc Cylindical Grinding Machine
| Model | Distance between centers | Swing | Wheel O.D. | Wheel spindle motor | |
|---|---|---|---|---|---|
 |
CNC PRECISION CYLINDRICAL GRINDING MACHINEG18-Ⅱ | 250 | 180 | 355 | 2.2kW |
 |
CNC PRECISION GRINDING MACHINEG18-ⅡFB | 60 | 180 | 305 | 2.2kW |
 |
CNC PRECISION CYLINDRICAL GRINDING MACHINEG300/G350 | 300・500・750 | 300・350 | 450・510・610 | 7.5kW・11.0kW |
 |
CNC PRECISION CYLINDRICAL GRINDING MACHINEG300F | 500・1000 | 300 | 455 | 7.5kW |
